Tri Level Sync Output
Number One, 75 1
Type 1080i (SMPTE 274M -5, 6) 59.94, 50, 60 Hz
720p (SMPTE 296M -2, 3) 59.94, 50, 60 Hz
1080p (SMPTE 274M -9, 11) 23.98, 24, 25 Hz
1080sF (RP211 -14, 16) 23.98, 24, 25 Hz
Output DC: ± 50 mV
Return Loss: > 30 dB to 30 MHz
General Specifications
Size
5.625” W x 0.8’’ H x 5.5’’ D (143 mm x 20 mm x 140 mm)
including connectors
Weight 1 lb
Power 12 volts, 4 watts
(100-230 VAC modular power supply not included)
Temperature Range 0 to 40° C ambient
Relative Humidity 0 to 95%, non-condensing
Due to ongoing product development, all specifications subject to change.
