ADJUSTMENTS
Adjusting Parameters from the Front Panel
From the front panel, use the Mode, Left Arrow, and Right Arrow buttons to select and adjust
parameters.
Pressing the Mode button cycles through the parameters that can be modified from the front panel.
The LED of the currently selected parameter will blink. A quick press of the Mode button advances to
the next editable parameter. A longer press of the Mode button will back up to the previous editable
parameter.
Pressing the Right Arrow or Left Arrow advances or backs up through the choices for the currently
selected parameter, or increases (Right Arrow) or decreases (Left Arrow) the value of the selected
parameter.
The LED of an edited parameter will blink for 15 seconds, after which time its value is stored in
memory. If power is interrupted before this 15 second timeout period has elapsed, the edited state will
not be not saved.
Pressing the Right Arrow and Left Arrow simultaneously restores the selected parameter to its
default value.
The controls and their indicators are described below:
Mode – This control selects the Mux behavior with the following choices:
• Mux – Embed audio into the SDI signal, replacing the existing embedded content or
cascading (augmenting the existing embedded content).
• Demux – Disembed audio that is in the SDI signal.
Group Select – This control selects the audio group for embedding or disembedding with the
following choices:
• 1 – Audio Group 1, 2 – Audio Group 2, 3 – Audio Group, 4 – Audio Group 4
Ch 1/2, Ch 3/4, Ch 5/6, and Ch 7/8 Gain Adjustment Indicators –
These controls allow for quick adjustment of Gain level for these two channel pairs. For independent
channel adjustment, and other controls, use the BrightEye PC or BrightEye Mac application.
Ch 1/2, Ch 3/4, Ch 5/6, and Ch 7/8 VU Indicators –
These indicators provide information about the level of the analog outputs on these channels. More
detailed indicators are available through the BrightEye Control application.
