Brighteye power supply information – Ensemble Designs BrightEye 71 HD/SD 8 Channel Analog Audio Embedder/Disembedder User Manual
Page 20
www.ensembledesigns.com
BrightEye 71 and 71-F - Page 20
HD/SD 8 Channel Analog Audio Embedder/Disembedder User Guide
TM
BrightEye 71 and 71-F
BrightEye Power Supply Information
Below is a list of power supplies and optional items that may have come with your BrightEye:
BEPS
BrightEye Individual Power Supply.
BEPS6
Spider Power Supply. This powers 6 single high BrightEyes or 3 double high BrightEyes.
BEPS6-RP
Redundant Power Supply for Spider.
BERKMT
BrightEye Rack Mount. This holds 6 single high BrightEyes or 3 double high BrightEyes,
or a combination.
BEBP
BrightEye Blank Panel. Single high, for empty slots in Rack Mount.
BEAC
Analog Audio Breakout Cable.
