ARAG BRAVO130 User Manual

Page 15

8.2

Treatment menu

Before each new spraying, perform the preliminary operations gathered together in the

Treatment

; to access the menu, proceed as follows:

1) Turn on the device by pressing and holding the

key; upon start-up, Bravo 13X performs the

self-diagnostics as indicated in sec. 6 - Start up, then automatically enters the

Spraying menu

2) From any function of the

Spraying menu

, press the

key;

3) Scroll through the entries in the

Treatment menu

by pressing the

and

keys and

select the function you wish to set by pressing the

key.

The following functions will appear in succession:
• Tank filling (see sec. 8.2.1)
• Field Number (see sec. 8.2.2)
• Total Field Reset (see sec. 8.2.3)
• Row Type (see sec. 8.2.4)
• Canopy Type (see sec. 8.2.5)
• User menu (see sec. 8.1)

4) To exit from the

Treatment menu

, press the

key (return to the

Spraying menu

For any questions regarding the method of selecting these functions, consult sec.
7 - Menus structure.
All the entries of the

User menu

are described in section 8.1 - User menu.

8.2.1

Tank filling

The

"TANK FILLING" function allows setting the quantity of liquid in the tank and, thus, calculating

the liquid remaining at the end of treatment (starting from the fill value, BRAVO 13X takes away
the quantity of liquid sprayed).
The computer also signals when the reserve level is reached with a buzzer and flashing indicator

on the display.

The liquid loaded in the tank can be set by following the procedure described below:
1) Scroll through the functions on the

Treatment menu

using the

and

keys and select

the entry

"TANK FILLING", followed by a number that indicates the quantity of liquid remaining in

the tank.
2) Confirm the selection by pressing

: the display will flash the maximum tank filling quantity.

3) To modify this value, use the

and

keys.

4) Confirm the value set by pressing the

key.

CONTINUES
