Extrusion Control & Extruder Monitor Units Chapter 4: Operation 21
4-4 Operation Procedures
Your controller uses a menu system to operate the blender. See the flow chart below to start
the unit and configure it to your preference.
Menu Structure
Starting from the #1 Startup menu, simply key in the number shown for each item. To get
back to the Startup menu from any display, press the BACKUP key.
MAIN MENU
1) Startup
2) Recipe
3) Setup and
Diagnostics
4) Printer (optional)
STARTUP
> Press 'Start'
RECIPE
EXTR/HAUL-OFF
WEIGHT/LENGTH
1) Weight per Length
Setting
2) Stretch Factor
EXTRUDER SPEED
CONTROL
1) User Flow Rate
DUAL CONTROL
1) Weight per Length
Setting
2) Stretch Factor
3) User Flow Rate
SETUP and
DIAGNOSTICS
1) Setup
2) Diagnostics
SETUP
DIAGNOSTICS
1) Extruder Haul-off
2) Data Transmission
3) Communications
4) Scale Readouts
5) Alarm Log
YIELD CONTROL
RATE MONITOR
1) System Setup
2) Factory Setup
3) Feeder Setup
MOTPOT CONTROL
1) Yield Control
2) System Setup
3) Factory Setup
4) Feeder Setup
PRINTER (optional)
1) Test Printer
2) Set Print Interval
3) Set Job Number
4) Print Data
SYSTEM SETUP
1) Communications
2) Set Time/Date
FACTORY SETUP
1) English/Metric
2) Set User Password
3) EC Options
FEEDER SETUP
1) Scale Calibration
2) Set Hopper Size
3) Set Alarm
Functions
4) Set Start Up Mode
HAUL-OFF W/L
1) Motpot RPM
2) Control Window
3) Max. Control RPM
4) Rate Deviation
5) Length per Pulse
6) W/L Format
EXTRUDER W/L
1) Motpot RPM
2) Control WIndow
3) Max. Control RPM
4) Length per Pulse
5) W/L Format
EXTRUDER SPEED
CONTROL
1) Motpot RPM
2) Control Window
3) Max. Control RPM
DUAL CONTROL
1) Haul Motpot RPM
2) Extr. Motpot RPM
3) W/L Control
Window
4) Rate Control
Window
5) Haul Control RPM
6) Extr. Control RPM
7) Rate Deviation
8) Length per Pulse
9) W/L Format
COMMUNICATIONS
SETUP
1) Set Baud Rate
2) Set ID
