NVR 3 Corporate User’s Manual
38
When you click on a channel which is set to such modes : Panorama mode with Wall
mounting, Double Panorama mode with Wall mounting, Panorama Focus mode with Wall
mounting and Double Panorama mode with Ceiling mounting, a clickable cursor will appear
on the view to allow you explore the image.
PTZ Operation
Select a fisheye mode; click the entire channel or a region of interest to navigate this view
 Use PTZ Panel controls to operate PTZ movements:
 Click the mouse anywhere on the view to pan/tilt, scroll the mouse wheel to zoom in/out.
 To reset the PTZ navigation area back to default viewing angle, right-click to bring up
channel menu, and then click “ Reset ”.
Note
By changing a the fisheye modes to the following five modes : Dewarping, Panorama, Double
Panorama, Panorama/Focus and Quad, the live stream of this channel will
Zoom in
Zoom out
Pan/Tilt
8 directional buttons
Zoom in / Zoom out
PTZ Controls on PTZ Panel
Note
Once a channel is changed to any of the following fisheye modes: Dewarping , Panorama ,
Double Panorama , Panorama/Focus or Quad , the resolution of this live stream will become
1920x1080, so will the resolution of the snapshot.
