sync mode. Make the adjustment when the vertical phase of the camera does
not match with other cameras.
6. View Angle Adjustment
The camera can be rotated 360° horizontally, 140° vertically and 60° 3’rd axis
view angles (as shown in Figure 8). Adjust the proper camera view angle as
needed. If a vari-focal lens is used, you may adjust the focus and zoom of
the lens to bring the object in focus. Be sure to loosen the locking screws on
the lens before you make adjustment.
Figure 8
Lens fixing Screws
140°
360°
60°
