21 6616-2211
Packing algorithm
When data arrives at the serial port of the EDW-120 there must be one or more
criteria fulfilled to trigger the EDW-120 to encapsulate the received serial data into a
frame and send it out on the network.
These criteria are setup using different parameters i.e. the ‘packing algorithm’. The default
settings are selected to be compatible to most applications but can be optimized to
the customer specific application. Detailed description can be received from the Web
configuration tool.
Advanced settings
Advanced settings configure the unit for special application requirements or special
interface functions, these settings are default disabled.
Detailed description can be received from the Web configuration tool.
Received data
Conditions
Packing
Transmitted data
Network
