16 6616-2211
Username and Password for configuration
The EDW-120 is username and password protected. These are used when connecting
with Web browser during configuration and with Telnet for diagnostics.
Default username: edw120
Default password: edw120
Browser Login
The Webtool has two different login accounts.
The first is the EDW-120 Guest account that only allows the user to read the units
settings but he has no rights to configure the unit in any way.This accounts Username
and Password are fixed and aren’t configurable
EDW-120 Guest
Username: guest
Password: guest
or
Username: anonymous
Password: anonymous
EDW-120 Config
The second account is the EDW-120 Config that gives the user rights to configure the
unit with new parameter values.This accounts Username and Password can also be
configured when the user are logged in as EDW-120 Config. Default Username and
Password are listed below.
Default Username: edw120
Default Password: edw120
3. Set DIP S1:1 to ‘Off’ and power cycle the EDW-120.
4. The unit is now ready for a complete configuration by the Web tool.
New Connection - Hyper Terminal
File
'EDW-120 IP CONFIGURATION'
Firmware : 4100-9000
-- Current IP configuration --
Local IP address : 169.254.100.100
Gateway address : 169.254.100.1
Subnet Mask address : 255.255.255.0
Press to select the value shown in braces,
or enter a new value.
Local IP address [169.254.100.100]?
Edit View Call Transfer
Connected 0:01:33 VT100 9600 8-N-1 NUM SCROLL CAPS Capture Print echo
Help
See also
configuration by
Web Tool on page
18
