Product description
The EDW-120 is an industrial Ethernet to serial interface adapter designed for harsh
environments.
It allows serial devices to interface through a new or existing Ethernet network. The
unit can support two RS-232, running at up to 115.2 kbit/s. Ethernet connection is via a
standard RJ-45 port with MDI/MDI-X.
The protocols used for network communication is UDP or TCP. This allows the
EDW-120 to be setup as a TCP-server or -client as well as an UDP unit.
Configuration of the unit
The EDW-120 can be easly configured via the onboard Web based configuration tool,
alternatively some functions can also be set by hardware DIP-switches on the PCB.
It is also possible to monitor and override the hardware settings by using the Web tool, if
that is done this is indicated by the RC LED (Remotely Controlled).
The serial port properties such as data rate, flow control and data bits etc. are
configured by the Web based configuration tool.
