6

Product Specifications
Cables Tested:

HDMI cables with Type A connectors
conforming to 1.0, 1.1, 1.2, 1.2a, 1.3,
1.3a, Category 1 and Category 2 cables

Tests Performed:

Tests for Opens, Shorts, Miswires

Test Modes:

Auto or Manual

Displays
Transmitter:

9 Red LEDs indicate test performed

Receiver:

9 Green LEDs indicate test results

Battery:

Standard 9v Alkaline Battery,
ANSI 1604A, IEC 6LR61

Size (approx):

Transmitter: 2.8" x 4.8" x 1.1"
Receiver: 2.3" x 1.2" x 1.1"
Combined: 2.8" x 5.9" x 1.1"

Weight (approx):

Transmitter: 0.305 lb
Receiver: 0.050 lb
Combined: 0.355 lb

Maintenance
No regular maintenance of the WireMaster HDMI is required. In
the event the product is defective or is damaged, please contact
Triplett for repair information.

TRIPLETT PRODUCT RETURN INSTRUCTIONS

In the unlikely event that you must return your Triplett
equipment for repair, the following steps must be taken.

1) Call 1-800-TRIPLETT to obtain a Return Material
Authorization (RMA) number from Customer Service.

2) Enclose a copy of the original sales receipt showing date
of purchase.

3) Clearly print the RMA number on the outside of the
shipping container.

4) Return to:

Triplett / Jewell Instruments
850 Perimeter Road
Manchester, NH 03103
ATTN: Repair Dept.
