Tri Tool 230B Beveler Flange Facer User Manual

Page 7

background image

7

Model 230B SP/FF

92-0725 : Rev. 030407

1

2

3

4

A

.006"/rev

(.15 mm/rev)

.013"/rev

(.33 mm/rev)

.018"/rev

(.46 mm/rev)

.024"/rev

(.61 mm/rev)

B*

.012"/rev

(.30 mm/rev)

.021"/rev

(.53 mm/rev)

.031"/rev

(.79 mm/rev)

.042"/rev

(1.07 mm/rev)

Actuator

Arm

Position

*Posittion B should be used for flange facing only.

Feed Rates for 230B SP

INDEX PLATE POSITIONS
