13
Model 230B SP/FF
92-0725 : Rev. 030407
32. 33-0063 SCREW, CAP, 5/16-18 X 2.75" 1
33. 33-0079 SCREW, CAP, 3/8-16 X 3.00" 12
34. 33-0293 SCREW, BUTTON HEAD, 5/16-18 X .75" 4
35. 33-0514 SCREW, SET, 5/16-18 X .38", CUP PT 1
36. 33-0517 SCREW, SET, 5/16-18 X .63, CUP PT 3
37. 33-0955 SCREW, GIB 1
38. 33-0995 SCREW, DRIVE 4
39. 33-1314 SCREW, SET, 3/8-16 X 1.50", HALF DOG 1
40. 34-0026 WASHER, FLAT 1
41. 35-0270 NUT, FEED 1
42. 39-0854 GEAR ASSEMBLY, FEED 1
43. 40-0045 SPRING, COMPRESSION 1
44. 44-0276 SPACER 1
45. 49-0091 HOLDER, TOOL 1
46. 66-0078 BASE, SLIDE 1
47. 66-0079 GIB, TAPER 1
Parts List, Single Point/Flange Facer (SP/FF) Continued
Item Part
No. No. Description Qty
