GENERAL
COUNTERBORING FUNCTION
Lock the Tool Slide in the flat position.
Replace the Tool Holder and the Insert with the Counterbore Tool Bit.
Insure that the cutting edge is facing out from the center.
Set the feed direction to neutral by moving the Feed Knob to the center position.
Feed System Set-Up
