Tri Tool 230B Beveler Flange Facer - Manual (Page 15)

15
Model 230B SP/FF
92-0725 : Rev. 030407
Parts List, Gearbox Assembly (P/N 19-0424)
Item Part
No. No. Description Qty
1. 19-0418 HOUSING, GEAR 1
2. 20-0364 SHAFT, MAIN 1
3. 29-0029 BEARING, BALL 2
4. 29-0133 ROD END 1
5. 30-0489 RING, RETAINING, INTERNAL 1
6. 30-0507 MOUNT, KEYLESS SHAFT 1
7. 30-0910 RING, RETAING, INTERNAL 1
8. 30-0911 PLUNGER, BALL 2
9. 30-0912 CLUTCH, ROLLER 1
10. 32-0305 PIN, MOD., DOWEL 2
11. 33-0052 SCREW, CAP 1
12. 33-0078 SCREW, CAP 2
13. 33-1533 SCREW, ASSEMBLY, FEED 1
14. 33-1535 SCREW, SHOULDER 1
15. 33-1536 SCREW, SHOULDER 1
16. 39-0482 GEAR, BEVEL 2
17. 42-0104 KNOB, FEED 1
18. 44-0275 SPACER, GEAR 1
19. 63-0096 ARM, ACTUATOR 1
