15
Model 212B-FF Flange Facer
92-0291 : Rev. 921230
ATTACHING THE FLANGE FACER
ATTACHING THE MODEL 212B-FF TO THE MODEL 212B
Remove the three Tool Holders from the Model 212B BEVELMASTER TM .
Mount the Model 212B-FF Flange Facer to the 212B BEVELMASTER TM and attach
with the six Mounting Screws provided.
Attach the two Tripper Block Assemblies to the side of the 212B
BEVELMASTER
TM .
Mounting the Model 212B-FF onto the Model 212B
