Checklist for Installation of Series Heating Cables
General Information
Project Number:
Electrical Contractor:
Unit Number:
Reference Number:
Customer Ref. Number:
Inspector:
Record 1: Prior to Installation
Cable Type:
Insulation Resistance (M Ohms):
Reel Length (M):
1
2
Single Phase
L-Earth
3 Phase
L
1
-Earth
Reel Number:
1
2
L
2
-Earth
L
3
-Earth
Tested By/Date:
Witnessed By/Date:
Record 2: After Cable Installation
Line Number:
Junction Box Number:
Equipment Number:
Unused Entries
Plugged Off:
Circuit/Heater Number:
Heater Length (M):
1
2
Circuit Switch Number:
Insulation Resistance (M Ohms):
Braid Connected
to Earth/Ground:
Single Phase
L-Earth
3 Phase
L
1
-Earth
Thermostat Number:
L
2
-Earth
L
3
-Earth
Tested By/Date:
Witnessed By/Date:
Record 3: After Thermal Insulation is Installed
Insulation Watertight:
Insulation Resistance (M Ohms):
Electrical Loop Resistance (Ohms):
Single Phase
L-Earth
Single Phase
L-L
3 Phase
L
1
-Earth
3 Phase
L
1
-L
2
L
2
-Earth
L
2
-L
3
L
3
-Earth
L
3
-L
1
Tested By/Date:
Witnessed By/Date:
Record 4: Final Commissioning
Panel Number:
Ambient Temp. (°C):
Breaker Number:
Pipe Temp. (°C):
Volts:
Recorded Amps
(after 5 min.):
Tested By/Date:
Witnessed By/Date:
*NOTE: Minimum acceptable insulation resistance should be 20 megohms for Records 1 and 2 and
5 Megohms for Record 3.
