Version 1.5 Page 15 of 18 SMT391 User Manual
The following table lists the internal SMT391 voltages that are derived from the
voltages that are provided over the daughter card power connector.
Voltage Description
D+3V3 Derived from D+3V3_IN
D+2V25 Derived from D+3V3 on SMT391
A+3V3 Derived from D+3V3_IN
VCO+5V0 Derived from D+5V0_IN
VCO+12V0 Derived from D+12V0_IN
ECL-5V2 Derived from D-12V0_IN
AGND Derived from DGND
Figure 12 – Internal Power Supply Voltages.
Module Dimensions
The following table lists the dimensions for the SMT391 and the SMT391-VP.
Description Value
Module Dimensions (Only SMT391)
Width: 63.5 mm
Length: 106.68 mm
Height: 21mm (Maximum)
Module Dimensions (SMT391-VP)
Width: 63.5 mm
Length: 106.68 mm
Height: 21mm (Maximum)
Weight TBD Grams (including heat sinks)
Figure 13 – SMT391-VP Dimensions.
