Model 216 User Guide

Issue 1, July 2014

Studio Technologies, Inc.

Page 9

compatible with standard RJ45 plugs,

etherCON allows a ruggedized and lock-

ing interconnection for harsh or high-reli-

ability environments. The Model 216’s

operating power can be provided by way

of the Ethernet interface using the Power-

over-Ethernet (PoE) standard. This allows

fast and efficient interconnection with the

associated data network. To support PoE

power management, the Model 216’s PoE

interface reports to the power sourcing

equipment (PSE) that it’s a class 2 (low

power) device. The unit can also be pow-

ered using an external source of 12 volts

DC. For redundancy, both power sources

can be connected simultaneously. If both

sources are connected PoE will power the

unit. Four LEDs display the status of the

network connection, PoE power source,

and Dante interface.

Configuration and Flexibility

Model 216 configurations are made using

twelve DIP switches and two pushbutton

switches. The 12-position switch array

configures parameters such as the push-

button operating modes, sidetone func-

tion, headphone control assignment, and

the system mode. The pushbuttons are

used to set the gain of the microphone

preamplifier and control the on/off status

of the microphone phantom power func-

tion. The switches and pushbuttons are

accessible via the bottom of the Model

216’s enclosure; the unit does not have to

be disassembled. Changes made to any

of the configuration parameters become

active immediately. To prevent unwanted

access to the configuration switches and

pushbuttons a security panel, included

with each unit, is attached to the bottom

of the enclosure.

In the world of broadcast and production

audio it’s fair to say that applications vary

widely. To this end, one or two additional

XLR connectors can easily be mounted

into the Model 216’s back panel. Multiple

3-position “headers” located on the Model

216’s circuit board provide technician

access to many of the input and output

connections. Using a variety of optional

factory-supplied modules and interface

cable kits allows a Model 216 to be opti-

mized to meet the needs of specific ap-

plications. For example, some applications

may prefer to use a multi-pin XLR connec-

tor to interface with a headset. This can

easily be accomplished by installing the

appropriate 6- or 7-pin XLR connector kit

and making a few simple connections.

Other applications may benefit from hav-

ing “mult” or “loop-through” connections,

something easily incorporated into a Model

216. And access to the relay contacts can

be made adding a 4-pin XLR connector kit.
Two general-purpose relay contacts are

provided on the Model 216’s circuit board.

Accessible using 3-pin “header” connec-

tors they allow specialized configurations

to be created. Under software control, the

form-A (normally open) solid-state relay

contacts follow the state of the main and

talkback 1 pushbuttons. Taking advantage

of the two locations provided for additional

XLR connectors, a technician may easily

implement a variety of functions such as

a tally indication or audio muting during

talkback.

Future Capabilities &

Firmware Updating

The Model 216 was designed so that its

capabilities can be enhanced in the future.

The primary additions will be in the area of

Dante remote control functionality. Once an
