13

Diagrams

HYDRAULIC DIAGRAM PARTS LIST

REF#

PART#

DESCRIPTION

QUANTITY

1

76-238

Wheel Motor

2

2

15-681

Hydraulic Hose 23"

4

3

15-682

Hydraulic Hose 46

3

/

4

"

2

4

15-685

Hydraulic Hose 101"

1

5

8832-33

3

/

4

" Suction Hose

2

18-040

Hose Clamp

4

6

15-839

Hydraulic Cylinder

1

7

15-687

Hydraulic Hose 75

1

/

2

"

2

8

15-301

Orbitrol

1

9

15-686

Hydraulic Hose 107

1

/

2

"

1

10

60-473

Hydraulic Oil tank

1

11

8917-26

3

/

8

" Suction Hose

1

18-040

Hose Clamp

2

12

26-016

Oil Filter

1

23-031

Replacement Filter

1

13

42-045

Hydraulic Hose

1

14

77-239

Hydrostatic Pump

1

15

30-098

Gear Pump

1

16

15-624

Cooler

1

17

15-683

Hydraulic Hose

1
