4 © 2013 SmartAVI, Inc.
INTRODUCTION
PART NO. QTY DESCRIPTION
NET-IP-PRO 1 NET-IP-PRO Device
PS5VDC2A 1 5VDC2A Power Supply
CCRS232-X 1 Serial male to male cross-over cable
The NET-IP-PRO is an RS-232 control module that allows most
SmartAVI switching matrixes to be controlled remotely via
HTTP or TELNET. Manage the switching functions of your ma-
trix with ease from anywhere in the world. With NET-IP-PRO you
can save present input/output configurations for easy access.
TELNET access provides transparent command control of your
matrix, perfect for use with automated third-party control software.
Note: Telnet access requires telnet or similar. First find the IP address us-
ing the “detect” application, or if you have configured the IP address manu-
ally, telnet the IP address port 23.
FEATURES
 Supports HTTP and TELNET control
 10/100 Ethernet Interface
 Up to 10 user-definable configurations
 Password Protected
 Up to 5 Users can Control the Matrixes
 IP Configuration via TCP/IP and RS-232
 Flexible control of several types of matrixes
WHAT’S IN THE BOX?
 Server Collocation
 Digital Signage
 Airports
 Dealer Rooms
 Control Rooms
 Audio/Visual Presentations
 Hotels/Resorts
APPLICATIONS
Power External 100-240 VAC/5VDC2A @10W
Dimensions 2.8125”W x 1”H x 3.375”D
Weight 0.5 lbs
Approvals UL, CE, ROHS Compliant
Operating Temp. 32-131°F (0-55 °C)
Storage Temp. -4-185 °F (-20-85 °C)
Humidity Up to 95%
TECHNICAL SPECIFICATIONS
