Calibrate
This command calibrates one of the coprocessor’s internal standards. You must supply two stable
references, 5V and 500mV, which are applied to external channels during board calibration. Exter-
nal channels used for the calibration must be properly configured and allowed to settle before issu-
ing the calibrate command. A board reset must be invoked after each range is calibrated.
COMMAND: (192 + Chan), (RangeCode), (CalData MSB), (CalData LSB)
RESPONSE:
(IgnoreThisValue)
VB Code Example:
‘*********************************************************************
‘ Calibrate one voltage range on a Model 417 board.
‘*********************************************************************
Sub CalRange(BasePort%, Chan%, RangeCode%, AppliedVolts!)
Dim TypeCode
As Integer
Dim Scalar
As Single
Dim Junk
As Integer
Select Case RangeCode
CASE 0: Scalar = 5000:
TypeCode = &H15
CASE 1: Scalar = 50000:
TypeCode = &H16
End Select
Call SetSensorType(BasePort, Chan, TypeCode)
Call Delay(900)
Call SendByte(192 + Chan)
‘Issue Calibrate command to 417
Call SendByte(RangeCode)
Call SendByte(AppliedVolts * Scalar)
Junk = ReadByte(BasePort)
‘Wait for 417 to calibrate
Call OUT(BasePort + 1, 0)
‘Reset the 417 board
Do: Loop While (INP(BasePort + 1) And FAULT)
End Sub
‘*********************************************************************
‘ Calibrate a Model 417 board. This snippet assumes 5.0000V is
‘ applied to channel 3 and 0.50000V is applied to channel 7.
‘*********************************************************************
Call CalRange(BaseAdrs, 3, 0, 5.0000)
‘Calibrate 5V range
Call CalRange(BaseAdrs, 7, 1, 0.50000)
‘Calibrate 500mV range
Table 10: Range codes for the Calibrate command
RangeCode
Range
0
5 V
1
500 mV
