Sensoray 811 User Manual
Page 9
9
Connector List
P1
PCI-Express Connector
J1
BNC: Composite Video Input for Channel-1
J2
BNC: Composite Video Input for Channel-2
J3
BNC: Composite Video Input for Channel-3
J4
BNC: Composite Video Input for Channel-4
J5
3.5mm AudioJack: Stereo/Mono Audio Input for
Channel-1
J6
3.5mm AudioJack: Stereo/Mono Audio Input for
Channel-2
J7
3.5mm AudioJack: Stereo/Mono Audio Input for
Channel-3
J8
3.5mm AudioJack: Stereo/Mono Audio Input for
Channel-4
J9
34-pin Connector:
break-in/out for
Composite Video Input for Channel-1, 2, 3, and 4
S-Video Input for Channel-1, 2, 3, and 4
Stereo/mono Audio Input for Channel-1, 2, 3, & 4
Digital Inputs for Channel-1, 2, 3, and 4
Digital Output for Channel-1, 2, 3, and 4
TB1~TB4
General Purpose Digital I/O: configurable
Digital Inputs for Channel-1, 2, 3, and 4
or
Digital Output for Channel-1, 2, 3, and 4
