Delta 31-750 - Manual (Page 5)

5
Fig. 2
Fig. 3
A Four Legs -
27-1/2 long
B Two Upper Front
and Rear Braces -
11-1/2 long
C Two Upper
Side Braces -
21-5/16 long
D Two Lower Front
and Rear Braces -
17-1/8 long
E Two Lower
Side Braces -
26-5/8 long
F M 8 Hex Nuts - (36)
G 3/8 Flat Washers -
(40)
H M8 x 16mm
Carriage Bolts - (32)
J M8 x 45mm Hex
Head Screws (4)
K Plastic Feet (4)
1. Bench Random
Orbital Sander
2. Dust Bag
3. Fence
4. 5/16 Flat Washer (2)
5. Fence Lock Knob (2)
6. Abrasive Disc
(Hook and Loop)
7. Abrasive Disc
(PSA-Pressure
Sensitive Adhesive)
8. Transition Pad -
For use with PSA
abrasive discs only!
* 1/8 Allen Wrench
(not shown)
* * 13MM and 14MM
W rench
(not shown)
8
7
6
5
4
3
2
1
A
K
J
H
G
F
E
D
C
B
