CBX500 INSTALLATION MANUAL
2
Figure B
Power switch (ON/OFF)
1
2
Device Chassis Grounding Selector
3
Mounting Holes (2)
5
4
I/O Extension Module Connector
Backup Module Connector
6
Indicator LEDs
RS485 Termination Resistance Switch
7
ID-NET™ Termination Resistance Switch
8
Auxiliary Port Connector
9
IP65 Fieldbus Module Connector
10
Standard Fieldbus Module Connector
11
Spring Clamp Terminal Blocks
12
Shield to Protection Earth Selector
13
Power Source Selector
14
3
5
7
8
9
11
13
14
1
2
4
6
10
12
