15
No. Description Ref.-No.
1 Blow-out cone cpl. (without blow-out grille) 359169
2 Blow-out grille, front 1095343
3 Lining plate , right / left 1103140
4 Insulation, right / left 1103141
5 Insulation, front 1103142
6 Lining plate , front 1103143
7 Blow-out grille, right / left 1103144
8 Lining plate , front / bottom 1103145
9 Safety temperature limiter (STB) 1101197
10 Temperature monitor (TW) 1103146
11 Lining plate , control panel 1103147
12 Control lamp, red (burner malfunction) 1105363
13 Control lamp, green (in operation) 1105514
14 Operating switch 1101188
15 Unit frame , cpl. 1103148
16 Base plate 1103149
17 Fan, cpl. 1108606
18 air suction grille, rear 1103150
19 Middle plate 1103151
20 Fan control thermostat (TR) 1101683
21 Insulation, rear 1103152
22 Lining plate , rear 1103153
23 Rosette for waste gas connection 1103285
24 Blow-out grille, side 1095344
29 Inspection cover, (with waste gas connection) 1103155
30 Seal for inspection cover 1103156
31 Waste gas suppressor (set = 6 piece 1103157
32 Combustion chamber, cpl. 1103158
not shown Oil nozzle (Steinen) 0,45 / 60°S 1103139
Spare Part List
We reserve the right to make modifications in dimensions and construction in the interests of technical progress.
When ordering spare parts please indicate ref. no. and machine no. (see model plate)!
