☆ Struction & components:
●
whole structure:
- 5 -
1. Main pole; 2. Assistant lamp Arms; 3. assistant lamps; 4.
drawer(once push to rebound, twice push to recover. Attention:
don’t pull it out of the position with heavy strength); 5. Infrared
Receiver Window; 6. CCD outshell; 7. CCD Cover; 8. Baselight;
9. Back Connections; 10. Side connections; 11. Control Panel.
●
back/side connections:
1
3
2
4
5
6
7
8
11
3
2
9
10
1 2 3
4
5 6
7
8
9
10
11
13
14
15
12
