Methods of usage:

There are three methods of operation: 1. control panel

2.remote controller 3. control it through RS-232 Port supported by

Computer’s Window System. Three methods can be executed

individually, and can be fixed up.

1.

Control Panel:(Note: pls check exact goods for the standard.)

System acquiesces the following:

It is into awaiting state when visualiser’s power on, and

“ ” light will be on, meanwhile it acquiesces PC output to
monitor and projector, thus PC’s monitor and projector’s light will
be on. Light of “volume+” and “volume-“ will be on, at this time
user can adjust volume. This visualiser adopts sensitive touch key,
just touch it with finger to use, don’t strike with heavy metal or
heavy strengh to prevent it from the nick.

Turn on:

After connection, press , and it turns from red shinning to

red, which means the visual presenter’s power is on. When heard
of “Bee” twice, users can start operation. Please try again to open
projector when user found that projector’s power was off.

- 9 -
