- 26 -

RGB

D-SUB 15 holes socket

Compound

video

RCA socket (1V±0.2Vp-p 75Ω)(*)

audio

stereo)

3.5 socket (-10dB 10KΩ above)

S-Video Micro DIN 4 socket(*)

USB

USB square socket(*)

Projector

232

D-SUB 9pin socket

Infrared

control

D-SUB 9pin socket

PC ON/OFF D-SUB 9pin socket

Projector

power

(central control function)

(*)

Output

ports

Power output

Screen power

(central control function)

(*)

Control

modes

Control panel, remote controller,

RS-232 control software, USB*

Power

12V DC 1.5A

Consuming ≤15W

Environm

ent

Temperature 0℃~40℃

UNFOLD:550×430×550 mm

Outer

size

W×D×H

FOLD:570×430×150 mm

USB function

central controlling function

For

selection

U Dish


Note:1. With “

*

” symbolize for basic, “

” symbolize for selection.

2.Design and specifications are subjected to change without

prior notice.
