Nortec MLP RO pump station - Manual (Page 9)

TI071GB-02 /06.11.09/LJ 9/12
Change of values
F5-F6-F7
Indication in display Explanation Range Standard
PASSWORD xxxx Password for changing values. 197
The password for changing operating parameters in F5-F6-F7 is 197.
If the password is set to 196, a text is shown in the display saying that the number of active
sections can be changed between 1-4.
The password is reset again by pressing the reset-key.
In the F5 range - Scaling of sensors
Indication in display Explanation Range Standard
1-HIE x.xx *LOE x.xx HIE - Highest electric signal from the
humidity sensors.
LOE - Lowest electric signal from the
humidity sensors. 1,00 - 25,00
0 - 20,0 V - 8,00
MA - 4.20
V - 2,00
MA - 1,80
1-HI xx *LO xx HI - Indication at the highest electric
signal.
LO - Indication at the lowest electric
signal.
10 - 200
0 - 200 80,0
20
2-HIE x.xx *LOE x.xx HIE - Highest electric signal from the
humidity sensors.
LOE - Lowest electric signal from the
humidity sensors. 1,00 - 25,00
0 - 20,0 V - 8,00
MA - 4.20
V - 2,00
MA - 1,80
2-HI xx *LO xx HI - Indication at the highest electric
signal.
LO - Indication at the lowest electric
signal.
10 - 200
0 - 200 80,0
20
3-HIE x.xx *LOE x.xx HIE - Highest electric signal from the
humidity sensors.
LOE - Lowest electric signal from the
humidity sensors. 1,00 - 25,00
0 - 20,0 V - 8,00
MA - 4.20
V - 2,00
MA - 1,80
3-HI xx *LO xx HI - Indication at the highest electric
signal.
LO - Indication at the lowest electric
signal.
10 - 200
0 - 200 80,0
20
4-HIE x.xx *LOE x.xx HIE - Highest electric signal from the
humidity sensors.
LOE - Lowest electric signal from the
humidity sensors. 1,00 - 25,00
0 - 20,0 V - 8,00
MA - 4.20
V - 2,00
MA - 1,80
4-HI xx *LO xx HI - Indication at the highest electric
signal.
LO - Indication at the lowest electric
signal.
10 - 200
0 - 200 80,0
20
