Nortec SAM-e User Manual
Page 53
SAM-e Installation | 50
FOR DUAL INLETS; INSULATE HEADER AS SHOWN ON PREVIOUS PAGE.
INSULATE SECOND INLET AS SHOWN
ROLL SHIELD TO
CREATE OVERLAP
DETAIL D
USE TIE WRAP 2538347 TO
SECURE IN PLACE.
D
ALWAYS PLACE TIE WRAPS AT THE
ENDS OF THE SHILED, 1/2 INCH IN.
WHEN 3 TIE WRAPS ARE NEEDE
POSITION ONE IN THE
APPROXIMATE MIDDLE CUT OFF
EXCESS END. TIGHTEN UNTIL
SNUG. DO NOT CRUSH
ORIENT END AS SHOWN
Field Retrofit of Installation Dual Inlet Headers
