Specifications 14
AV-3G-XMUX User Manual Rev. B
5.3.1 Packet or UART mode
Baud rates 9600 to 115200
Data length 7 or 8 bits
Parity None, odd or even
Stop bits 1, 1.5 or 2 bits
5.3.2 GPI mode
Raw data sampling frequency 93750 Hz
5.3.3 Connector
Input standard RS422
Packet mode output standard RS485
GPI mode output standard RS422
Connector 8P8C Modular jack (RJ45)
5.4 GPI input/alarms
Status good alarm is active (low impedance to ground) when module is operating normally. Laser
failure alarm may also be used as a laser kill input.
Input Laser kill (active ground)
Alarms Status good, no video input lock, laser failure.
Connector 8P8C Modular jack (RJ45)
Signal type Open drain transistor with free-wheel diode.
Maximum voltage 100 V
Maximum current 150 mA
5.5 Latencies
Video latency is variable due to the de-glitcher but the values below apply when the video signal
is first applied. Other latency values are maximum values.
