Specifications 13
AV-3G-XMUX User Manual Rev. B
Inputs and outputs according to AES3-2003
Minimum sampling frequency 30 kHz
Maximum sampling frequency 100 kHz
Embedded audio word length 24 bits
Embedded audio Channel status As received when isochronous, otherwise fixed
Sample rate converter dynamic range 139 dB(A) @ 1 kHz
Mono shuffler maximum delay 1.37 s
5.2.1 C1 backplane
Impedance 110 ohm transformer balanced
Connector 25 pin D-sub
Number of ports 8
5.2.2 C2 and C3 backplanes
Impedance 75 ohm unbalanced
Connector BNC
Number of ports C2 8
Number of ports C3 4
5.2.3 AAV-3G-XMUX-C2 backplane (with one of the AES8 audio converters)
Impedance 110 ohm transformer balanced
Connector 15 pin D-sub
Number of ports 8
5.3 Asynchronous Data
Embedded into the User bits in one of the embedded audio channels.
