Cobramatic
®
Owner’s Manual - page 13
Main P.C. Board Connections
J14
J2
J1
J3
J4
FRONT
PANEL
FRONT
PANEL
BRAKE
SOLENOID
J7
J8
J5
J6
SLAVE
MOTOR
TRANSFORMER
115 VAC Contactor Out
115 VAC Contactor Out
Input Power - 115 VAC
Input Power - 115 VAC
Posa Start Welding Ground
Closing Contacts Out
Closing Contacts Out
Chassis
Ground
CURRENT
SENSOR
REMOTE
POTENTIOMETER
