DS_V48SR15004_06122007 14
PART NUMBERING SYSTEM
V 48 S R 150 04 N R F A
Type of
Product
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF
Logic
Pin
Length/Type
Option Code
V - 1/16
brick
48V S - Single R - Regular 150 - 15V 04 - 4A N- Negative
(Default)
P- Positive
R - 0.170”
(Default)
N - 0.145”
K - 0.110”
M - SMD
F- RoHS 6/6
(Lead Free)
A - Standard Functions
MODEL LIST
MODEL NAME INPUT OUTPUT EFF @ 100% LOAD
V48SR1R225NRFA 36V~75V 1.2A 1.2V 25A 84.0%
V48SR1R525NRFA 36V~75V 1.4A 1.5V 25A 85.0%
V48SR1R825NRFA 36V~75V 1.6A 1.8V 25A 87.0%
V48SR2R520NRFA 36V~75V 1.8A 2.5V 20A 89.0%
V48SR3R320NRFA 36V~75V 2.4A 3.3V 20A 90.5%
V48SR05013NRFA 36V~75V 2.3A 5.0V 13A 91.0%
V48SR12005NRFA 36V~75V 2.3A 12V 5.5A 91.0%
V48SR15004NRFA 36V~75V 2.3A 15V 4.4A 90.5%
Default remote on/off logic is negative and pin length is 0.170”
For different remote on/off logic and pin length, please refer to part numbering system above or contact your local sales office.
CONTACT: www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
[email protected]
Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
[email protected]
Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email:
[email protected]
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its
use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license is granted
by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these specifications
at any time, without notice
.
