Keypad
Quick Reference Guide
19
Keypad
The Pegaso is available with a 19-key keypad. Refer to the PRG for information
on configuring the keypad.
Table 3. Keypad Overview - Special Keys
System Tray Keyboard Indicators
The System Tray Keyboard Indicators are located at the bottom of the display.
The most recently activated state is to the left if more than one state is active.
Scroll between icons to view the active modes.
Table 4. Input States and their System Tray Indicators
Key Name
Function/Description
Press
to access upper case alpha characters and symbols on the
19-key keypad.
Numeric
Keys
In
Normal
mode, use the numeric keys to enter numbers. In
Alpha
mode
these keys can be used to type uppercase letters or punctuation.
Press
to enter the FN input state. Use FN mode to access additional
features and operations.
A customizable keypad overlay will be available for order, allowing you to
remap the Keypad to your specifications.
Press
Power
to put the Pegaso into sleep (suspend) mode if it is currently
running, and wake up (resume) the unit if it was in sleep mode. Press and
hold it briefly to turn off the unit.
Press
to activate the laser scanner.
4-Way
Rocker
Key
Press the edge of the 4-way rocker key to move the cursor or highlighted text
entry during a menu/list selection. In a text window:
The
arrow moves the cursor
up
one line.
The
arrow moves the cursor to the
right
one character.
The
arrow moves the cursor
down
one line.
The
arrow moves the cursor to the
left
one character.
Used to initiate or end
VOIP
when
VOIP
software is installed.
Icon
State
Function
Alpha
Mode
Press
to enter uppercase alpha characters and symbols. When
in Alpha mode, the current alpha character is displayed by a system tray
keyboard indicator.
Alpha mode is persistent, which means that the system stays in Alpha
mode until you press
again.
Fn Mode
Press
to enter FN mode.
is independent of the
key.
Use FN mode to access the features and operations on the keypad.
