Dimplex DF3215 User Manual

Page 16

UPPER LIGHT BULB REQUIREMENTS

Quantity of 2 clear chandelier or candelabra bulbs with an E-12 (small) socket base, 25 watt
rating.
DO NOT EXCEED 25 WATTS PER BULB

To access the upper light bulb area:

1. Open the bi-fold doors.
2. Remove upper light bracket with a
screwdriver.
3. Replace bulb.
4. Reassemble in the reverse order
as

above.

PURIFIRE™ FILTER
The Purifire™ filter supplied in your fireplace is reusable and washable. The filter should be
cleaned or replaced on average once a year. To clean the filter gently tap filter on a hard
surface to dislodge any loose dirt or debris, and then clean with water. No soap or cleaning
products are recommended. The filter size is 20” X 10” X 1” rated at MERV 10. If using an
after market filter follow the manufacturers recommended replacement instructions.

To replace filter:

1. Open the bi-fold doors.
2. Remove the 3 mounting screws from the air filter bracket.
3. Remove the air filter bracket assembly from the firebox.
4. Slide filter out of air filter bracket.
5. Reassemble in reverse order as above.
NOTE
If after market air filter is used ensure it is installed according to the manufacturers
recommended instructions.

Mounting Screws

Air Filter Bracket

Air Filter

Upper Light Bracket

Upper Light

Screw

FIGURE 9

FIGURE 10
