Repair Applications Kreg Jig ® HD Screw Features
For repair applications, remove the
Stop Block from the Drill Guide,
and clamp the Guide directly to
the workpiece. The position of the
Depth Collar on the drill bit does
not change. In situations where
using a clamp is not possible, you
can fasten the Drill Guide directly
to the workpiece by driving a
screw through the hole in the center
of the guide, as shown.
The removable Stop Block allows you to use your Kreg Jig ® HD to repair or
reinforce existing joints.
HD Screws are designed to match the ruggedness of "2X" construction. The robust
#14 screws feature the same case-hardened body and Protec-Kote
™ anti-corrosion
coating as our deck screws
Extra-large fl at-bottom washer head
Firmly seats on the pocket-hole
shoulder to resist pull-through.
#3 Square Drive
For reduced cam-out.
Three Protec-Kote™ anti-corrosion layers
Protects against rusting in a wide variety
of outdoor applications. Perfect for ACQ
treated lumber. Case-Hardened Steel
No bending. No breaking.
Self-Tapping Tip
Faster and easier driving.
