PowerH SERIES
28 Owner’s Manual
Illustration 3.5 shows the structure of the MODULE CONFIG menu of a PowerH SERIES amplifier with an
installed RCM-26 remote control module.
The following provides detailed information about the individual items of the MODULE CONFIG menu.
MODULE CONFIG/Preset: The name of the currently active
preset is displayed. Pressing the ENTER button opens the
Load Preset dialog box, which allows the user to select a preset
by pressing the Up/Down buttons.
Pressing the ENTER button opens a safety dialog box, which lets
the user select whether he actually wants to load the selected
preset by pressing the Up/Down buttons to either select YES or
NO. When YES has been selected, pressing the ENTER button
loads the selected preset and the display returns to the MODULE
CONFIG menu. When NO has been selected, the selected preset
is not loaded. The power amp’s currently active preset is not
changed and the MODULE CONFIG menu reappears on the
display.
Illustration 3.5: Structure of the Module Config menu (RCM-26)
CAUTION:
The selected preset must be suitable for the use with the connected loudspeaker com-
ponents. A incorrectly adjusted preset or incompatible preset can cause serious damage
to the connected speaker systems.
EXIT
Preset
CAN-Baudrate
Audio-Input
Power
