DATABRIEF
DB_NC12S30A_40A_05282008

FEATURES

Š High

efficiency:

93% @ 12Vin, 5V/30A out

92% @ 12Vin, 5V/40A out

Š

Voltage and resistor-based trim

Š

No minimum load required

Š

Output voltage programmable from

0.9Vdc to 5.0Vdc via external resistors

Š Fixed

frequency

operation

Š

Input UVLO, output OVP, OTP, OCP, SCP

Š Remote

ON/OFF

(default:positive)

Š Remote

Sense

Š

Power good function

Š

ISO 9001, TL 9000, ISO 14001, QS9000,

OHSAS18001 certified manufacturing

facility

Š

UL/cUL 60950 (US & Canada) Recognized,

and TUV (EN60950) Certified

Š

CE mark meets 73/23/EEC and

93/68/EEC directives

APPLICATIONS

Š DataCom

Š

Distributed power architectures

Š Servers

and

workstations

Š

LAN / WAN applications

Š Data

processing

applications

Delphi NC Series Non-Isolated Point of Load

DC/DC Power Modules: 12Vin, 0.9V-5Vout, 30A/40A

The Delphi NC30/NC40 Series, 12V input, single output, non-isolated

point of load DC/DC converters are the latest offering from a world

leader in power systems technology and manufacturing -- Delta

Electronics, Inc. The NC30/NC40 series operates from a 12V nominal

input, provides up to 40A of power in a vertical or horizontal mounted

through-hole package and the output can be resistor- or

voltage-trimmed from 0.9Vdc to 5.0Vdc. NC30/NC40 series has built-in

current sharing control and multiple NC30/NC40 series modules could

be paralleled together to provide even higher output currents.

NC30/NC40 provides a very cost effective point of load solution. With

creative design technology and optimization of component placement,

these converters possess outstanding electrical and thermal

performance, as well as extremely high reliability under highly stressful

operating conditions.

OPTIONS

Š

Vertical or horizontal versions

Š

Negative On/Off logic
