Standard Display Mode

32

If the signal from the system equals the standard signal mode, the screen will adjust automatically.
If the signal from the system does not equal the standard signal, adjust the display mode as shown below
referring to your video card instructions. Otherwise there will be no picture or only power may turn on.

Resolution

Horizontal (KHz)

Vertical (Hz)

Clock Frequency (MHz) Polarity (H/V)

640 x 350

720 x 400

VGA, 640 x 480

VGA, 640 x 480

VGA, 640 x 480

SVGA, 800 x 600

SVGA, 800 x 600

SVGA, 800 x 600

XGA, 1024 x 768

XGA, 1024 x 768

XGA, 1024 x 768

WXGA, 1280 x 768

WXGA, 1366 x 768

31.469

31.469

31.469

37.500

37.861

37.879

46.875

48.077

48.363

56.476

60.023

60.023

60.023

70.086

70.087

59.940

75.000

72.809

60.317

75.000

72.188

60.004

70.069

75.029

75.029

75.029

25.175

28.322

25.175

31.500

31.500

40.000

49.500

50.000

65.000

75.000

78.750

78.750

78.750

+ / -

- / +

- / -

- / -

- / -

+ / +

+ / +

+ / +

- / -

- / -

+ / +

+ / +

+ / +
