DS_E24SR05012_01032008


14

PART NUMBERING SYSTEM

E 24 S R 050 12 N

R

F

A

Type of

Product

Input

Voltage

Number of

Outputs

Product

Series

Output

Voltage

Output

Current

ON/OFF

Logic

Pin

Length/Type

Option Code

E - Eighth

Brick

24V

S - Single

R - Regular 050 - 5.0V

12 - 12A

N - Negative

(Default)

P - Positive

R - 0.170”

(Default)

N - 0.145”
K - 0.110”
M - SMD

F- RoHS 6/6
(Lead Free)

A - Standard

Functions

MODEL LIST

MODEL NAME

INPUT

OUTPUT

EFF @ 100% LOAD

E24SR3R320NRFA 18V~36V

5.0A 3.3V 20A

90%

E24SR05012NRFA 18V~36V

4.2A 5.0V 12A

90.5%

E24SR06508NRFA 18V~36V

3.4A 6.5V 8A

90.5%

E24SR12005NRFA

18V~36V

4A 12V 5A

90.5%

Default remote on/off logic is negative and pin length is 0.170”
For different remote on/off logic and pin length, please refer to part numbering system above or contact your local sales office.















CONTACT:

www.delta.com.tw/dcdc

USA:
Telephone:

East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:

[email protected]

Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:

[email protected]

Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email:

[email protected]


WARRANTY

Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.

Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its
use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license is granted
by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these specifications
