6

DO-IT-YOURSELF MAINTENANCE

29

HXDFL342

5 Door (Tail gate)

1. Open the tail gate.

2. Remove the cover with a flat blade screw-

driver.

(1) Stop/Tail light
(2) Rear turn signal light

HXDFL1017

3. To replace the rear combination light, re-

move it from the bulb holder and install the
new bulb.

(2)

HXDFL335

4. To replace the rear combination light, re-

move it from the bulb holder and install the
new bulb.

(1) Stop/Tail light
(2) Side marker light
(3) Rear turn signal light
(4) Back up light

5 Door (Luggage compartment)

1. Open the tail gate.

2. Remove the mounting screws of the rear

combination light with a flat blade screw-
driver.

HXDFL334

(1)
