Hyundai 2006 Elantra - Manual (Page 208)

6 DO-IT-YOURSELF MAINTENANCE
10
1. Put a new wiper blade onto the wiper arm and
lower the wiper blade at the level of the wiper
arm as shown in the drawing.
2. Raise the wiper blade lightly and pull up it.
HHR5049
HHR5050
To install the wiper blade G080B01HR-GAT
Replacing the Wiper Blades
To replace the wiper blades, raise the wiper to
the vertical.
To remove the wiper blade
1. Push down the wiper blade with the locking
clip (1) pressed to detach it from the wiper
arm.
HHR5048
(1)
