KEY PART
NO. NUMBER DESCRIPTION QTY.
1 ** Burner Assembly Base 1
2 114443-01 Burner Pan Assembly 1
3 11165 Screw #10 x 5/8 MD TR BLK 12
4 108763-01 Tube Burner 1
5 104506-25 Pan Burner Orifice (Natural Gas #47) 1
104506-20 Pan Burner Orifice (Propane/LPGas #56) 1
6 108866-01 Pilot Assembly (Natural Gas) 1
108866-02 Pilot Assembly (Propane/LP Gas) 1
7 11102 Screw #8-32 x 3/8 PPH Zinc 2
8 108755-01 Pilot Bracket 1
9 104506-26 Tube Burner Orifice (Natural Gas #50) 1
14544 Tube Burner Orifice (Propane/LPGas #59) 1
10 14528 Brass Elbow Fitting 1
11 14554 Tubing Assembly 1
12 14500 Brass Fitting 2
13 14569 Electronic Valve (Natural Gas) 1
14570 Electronic Valve (Propane/LP Gas) 1
14 14253 Flexible Gas Line 1
15 11107 Screw #10-32 x 1/4 PPH Zinc 4
16 26808 Valve Bracket 1
17 26827 Switch Bracket 1
18 11147 Screw #10-24 x 1/2 PPH Zinc 2
19 11186 Screw #8-32 x 1 Zinc 4
20 14115 Spade Tongue Connector 1
21 14120 Spade 1/4 Female Connector 4
22 14126 16 GA Green Wire (Ground) 1
23 14129 Transformer, 24V 1
24 14134 18 GA Black Wire 5
25 14149 Spade 1/4 Right Angle Connector 4
26 110286-01 Ignition Module Synetek 1
27 17223 Magnet 2
28 23416 Electronic Components Board 1
29 108863-01 24" Supply Connect Plug 1
30 11201 Nut #8-32 Hex Zinc 4
31 110986-01 Air Baffle, (Natural Gas Only) 2
110986-02 Air Baffle, (Propane/LP Gas Only) 2
32 108761-01 Grate Assembly 1
33 108754-01 Grate Base 1
** Part not available for field replacement.
PARTS LIST
Models (V)V36EN-B, (V)V36EP-B, VV36ENC1, VV36EPC1,
VV36ENSC1, VV36EPSC1, VV36EPHC1 and VV36ENHC1
PARTS LIST
BURNER ASSEMBLY FOR MODELS
V36EN-A, (V)V36EN-B, (V)V36EP-B,
VV36ENC1, VV36EPC1, VV36ENSC1,
VV36EPSC1, VV36EPHC1 AND VV36ENHC1
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 34 of this manual.
