PARTS LIST
Models (V)V36EN-B, (V)V36EP-B, VV36ENC1, VV36EPC1,
VV36ENSC1, VV36EPSC1, VV36EPHC1 and VV36ENHC1
PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 34 of this manual.
** Part not available for field replacement.
(V)V36EN-B VV36ENS-B VV36ENH-B
(V)V36EP-B VV36EPS-B VV36EPH-B
KEY VV36ENC1 V36ENS-B V36ENH-B VV36ENSC1 VV36ENHC1
NO. VV36EPC1 V36EPS-B V36EPH-B VV36EPSC1 VV36EPHC1 DESCRIPTION QTY.
1 ** ** ** ** ** Firebox Assembly 1
2 ** ** ** ** ** Face Weldment 1
3 108010-01 108010-01 108010-01 — — Door Assembly (V Models Only) 1
108010-02 — — 108010-02 108010-02 Door Assembly (VV Models Only) 1
4 108011-01 108011-01 108011-01 108011-01 108011-01 Top Louver Assembly 1
5 108011-02 108011-02 108011-02 108011-02 108011-02 Bottom Louver Assembly 1
6 108015-01 108015-01 108015-01 108015-01 108015-01 Fireplace Top 1
7 108016-01 108016-01 108016-01 108016-01 108016-01 Fireplace Top Insulation 1
8 ** ** ** ** ** Fireplace Surround 1
9 109082-01 109082-01 109082-01 109082-01 109082-01 Heat Shield 1
10 108032-01 108032-01 108032-01 108032-01 108032-01 Log Set 1
10-1 109128-01 109128-01 109128-01 109128-01 109028-01 Front Log (Log 1) 1
10-2 109129-01 109129-01 109129-01 109129-01 109129-01 Rear Log (Log 2) 1
10-3 109130-01 109130-01 109130-01 109130-01 109130-01 Crossover Log (Log 3) 1
10-4 109131-01 109131-01 109131-01 109131-01 109131-01 Top Log (Log 4) 1
10-5 109132-01 109132-01 109132-01 109132-01 109132-01 Left Log (Log 5) 1
10-6 109133-01 109133-01 109133-01 109133-01 109133-01 Base Log (Log 6) 1
11
—
110989-02 111215-02 110989-01 111215-01 Left Refractory Brick Panel 1
12
—
110991-02 111217-02 110991-01 111217-01 Rear Refractory Brick Panel 1
13
—
110990-02 111216-02 110990-01 111216-01 Right Refractory Brick Panel 1
14 108076-01 108076-01 108076-01 108076-01 108076-01 Burner Base Gasket 1
15 108719-01 108719-01 108719-01 108719-01 108719-01 Screen Rod 1
16 12105 12105 12105 12105 12105 Screen 2
17 11418 11418 11418 11418 11418 Push-On Nut 2
18 14123 14123 14123 14123 14123 Strain Relief 1
19 21171 21171 21171 21171 21171 Gas Knock-Out Cover 2
20 24353 24353 24353 24353 24353 Handy Box Assembly 1
21 24460 24460 24460 24460 24460 Gas Conduit Assembly 1
22 114352-03 114352-03 114352-03 114352-03 114352-03 Burner Assembly (Natural Gas) 1
114352-04 114352-04 114352-04 114352-04 114352-04 Burner Assembly (Propane/LP Gas) 1
PARTS AVAILABLE - NOT SHOWN
25487 25487 25487 25487 25487 Lava Rock/Bag Assy 1
27253 27253 27253 27253 27253 Notice Label 1
55240 55240 55240 55240 55240 Vent Label 1
