Replacing the Light Bulbs
Light bulb replacement is considered to be a homeowner
maintenance operation. If the lights do not work, before replacing
them, please consult the
Problem Solution Guide on page 30.
To replace the light bulbs, follow these steps:
Turn off power to the oven at the main power supply.
Gently insert the pointed end of the supplied lens pry stick
under the center edge of the lens cover. Hold your hand
under the lens for support and pry it loose. Pull the lens cover
straight out.
Using a glove, insert the new bulb into the socket. Replace the
light bulbs only with Dacor
Part No. 100429, available from
any authorized Dacor parts dealer.
IMPORTANT: Do not touch the replacement halogen light
bulbs with your fingers. Halogen bulbs are sensitive to the oils
from your hand. The oils from your hand will stick to the bulb
and cause it to burn out faster than normal.
When reinstalling the lens cover, line up the cut-out on the
inside rim with the light socket. Gently press it into its original
position.
Turn the power to the oven back on at the main power supply.
Reset the clock (see page 9).
1.
2.
3.
4.
5.
6.
Cleaning and Maintenance
Light Bulb
Socket
Lens Cut Out
Light fixture
in oven wall
Lens
WARNING
To prevent electrical shock and/or personal injury, make
certain that the oven and light bulb(s) are cool and that
power to the oven has been turned off at the main power
supply before replacing the light bulb(s).
Always make sure the lens covers are in place when using
the oven. The lens covers protect the bulbs from breakage.
Use the pry stick with caution. Do not cause uneven stress
on the lens cover.
Replacing the lens cover without lining up the cut-out with
the light socket will damage the light fixture. •
•
•
•
Lens Pry Stick
