Greenheck Temperature Interlock (471738) - Manual (Page 2)

2 Temperature Interlock
Table of Contents
Product Specification . . . . . . . . . . . . . . . . . . . . . . . . 1
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Receiving and Handling . . . . . . . . . . . . . . . . . . . . . . . 2
Installation
Hood
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Duct Collar Mounting . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Connections
Thermostat
Connections . . . . . . . . . . . . . . . . . . . 4
Breaker Panel to Control Box or
Fan Control Center . . . . . . . . . . . . . . . . . . . . . . 4
Circuit Connections . . . . . . . . . . . . . . . . . . . . . . . 4
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Control Circuit Diagrams . . . . . . . . . . . . . . . . . . . . 5-6
Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . 8
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Codes and Standards Compliance . . . . . . . . . . . . . . 8
Our Commitment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Receiving and Handling
Upon receiving the equipment, check for both obvious
and hidden damage. If damage is found, record all
necessary information on the bill of lading and file
a claim with the final carrier. Check to be sure that
all parts of the shipment, including accessories, are
accounted for. Make sure the equipment does not suffer
any heavy vibrations or knocks.
Storage
If a temperature interlock must be stored prior to
installation it must be protected from dirt and moisture.
Indoor storage is recommended. For outdoor storage,
cover the hood with a tarp to keep it clean, dry, and
protected from UV (ultraviolet) radiation damage.
Improper storage which results in damage to the unit
will void the warranty.
®
