Parts list, Troubleshooting – Greenheck ERM 36 & 52 (456785) User Manual
Page 7
Parts List
1. Cassette
2. Energy Wheel Segments
3. Energy Wheel Drive Belt and Pulley
4. Energy Wheel Motor
5. Cabinet
The ERM mounting bracket kit has a separate parts list.
Troubleshooting
Symptom
Possible Cause
Corrective Action
Energy Wheel
does NOT turn
Air seals are too tight.
See air seals under Start-Up section.
Broken belt.
Replace.
No power to wheel motor.
Make sure wheel drive is plugged in. Verify
power is available.
Energy Wheel
runs intermittently
Wheel motor overloads are tripping due
to rubbing between wheel and air seals.
Recheck air seals, make sure they are not
too tight. See Air Seals under Start-Up
section.
1
2
4
5
3
4
7
Energy Recovery Modules
®
