Dimensional Data and Specifications
Model A B C D E F G H Voltage Hertz Phase Amps
Motor
HP
Weight (lbs.)
Cabinet Cassette
ERM-36S-15 44 1 ⁄
2
42 34 1 ⁄
4
5 14 3 ⁄
4
16 3 ⁄
8
16 5 ⁄
8
14 5 ⁄
8
200-230/460 50/60 1 0.6 1/20 95 80
ERM-36H-15 44 1 ⁄
2
42 34 1 ⁄
4
5 14 3 ⁄
4
16 3 ⁄
8
16 5 ⁄
8
14 5 ⁄
8
200-230/460 50/60 1 0.6 1/20 95 80
ERM-36H-30 44 1 ⁄
2
42 34 1 ⁄
4
5 14 3 ⁄
4
16 3 ⁄
8
16 5 ⁄
8
14 5 ⁄
8
200-230/460 50/60 1 0.6 1/20 95 118
ERM-52S-15 60 3 ⁄
4
58 1 ⁄
4
50 1 ⁄
2
6 1 ⁄
2
17 3 ⁄
4
16 3 ⁄
8
16 5 ⁄
8
14 5 ⁄
8
200-230/460 50/60 1 1.2 1/6 135 188
ERM-52H-15 60 3 ⁄
4
58 1 ⁄
4
50 1 ⁄
2
6 1 ⁄
2
17 3 ⁄
4
16 3 ⁄
8
16 5 ⁄
8
14 5 ⁄
8
200-230/460 50/60 1 1.2 1/6 135 188
ERM-52H-30 60 3 ⁄
4
58 1 ⁄
4
50 1 ⁄
2
6 1 ⁄
2
17 3 ⁄
4
16 3 ⁄
8
16 5 ⁄
8
14 5 ⁄
8
200-230/460 50/60 1 1.2 1/6 135 220
All dimensions shown are in inches.
Model Inspection or Service Removal
ERM-36 22 42
ERM-52 30 58
All dimensions shown are in inches.
Installation Clearances
Provide proper clearance for cassette inspection, service or removal. Do not install ducting, piping or wiring
where it will interfere with cassette removal.
C
D
B
E
A
H
G
F
5 Energy Recovery Modules
®
